Products lineup

Specifications required to the actuator are widely variety. Various specifications are required depending on the needs or used environment such as stroke, rigidity, size, speed, carrying weight accuracy etc. IAI has prepared abundant lineup and wide variation responding to the needs. The most appropriate actuators which meet the needs of each customer sensitively will be provided.

PICK UP PRODUCT

procdubt ouc

This is a motorized cylinder which achieved the maximum speed of 1.5 times, carrying weight of 2 times when used combining with the new controller "POWERCON 150 PCON-CA".

＜Feature＞

  1. Fulfilled lineup with the motor straight type, motor turned type and clean room type.
  2. Rod type (radial cylinder) containing the guide mechanism is capable for long stroke (500mm) and radial loading.
  3. Improved maintenance performance since the motor can be replaced with a screw.
  4. Replaceable from existing unit since the hole of slider type is compatible with RCP2.

Slim small sized Robo Cylinder Series

product_list1

Robo Cylinder in the next generation realized "Smaller".

  • The size equivalent to the air cylinder was realized by mounting the newly developed motor.
  • The shape and convenience like the air cylinder.
  • Abundant lineup with slider type, rod type, table type linear servo type etc.

Robo Cylinder Series

product_list1

Low cost with high accuracy and high rigidity. Further, running cost is 1/5 of air cylinder.

  • Multiple positioning, and easy change of speed or acceleration.
  • RCA/RCA2/RCS2 Series which mounts servo motor are high speed and high weight capacity.
  • Pulse motor RCP2/RCP3/RCP4 Series which realized low cost and high performance can be used for wide range of purposes.
  • Abundant lineup of next generation with actuator type and linear servo type which are quiet and good at environmental performance by the energy saving.

ISB/ISPB Series

product_list1

Repeated positioning accuracy of ±0.01mm and maximum speed of 2.500mm/s were realized by the mounting of high rigid base linear guide and AC servo motor.

  • Intelligent actuator operated by the program without commands from the upper level.
  • Exclusive X, Y and Z axis are prepared. Easy multi-axis operation by the exclusive controller.
  • Maximum acceleration was increased to 1.2G.
  • Abundant variation applicable to the purpose commencing from vertical/rotation integrated type.

Applicable to the clean rooms.

product_list1

Exclusive clean room series corresponding to the cleanness degree 10.

  • Cleanness degree 10 was realized by the closed structure with stainless sheet.
  • Wide range of variation from SCARA robot, orthogonal type robot, Robo Cylinder until gripper are prepared.

Drip proof type

product_list1

The power under the bad conditions is exerted by the protection code IP54 - IP64

  • Protection code applied to the bad environment in the dust or the water is poured.
  • Protection structure can be selected from IP54/IP56/IP57 depending on the environmental conditions where used.
  • It can be selected from slider type/rod type/SCARA type depending on the purpose.

LSA/LSAS Series

product_list1
Linear servo actuator

Full lineup fulfilled from small type to the carrying weight capacity 120kg, or maximum stroke up to 4m.

  • Enables significant deduction of cycle time with the high acceleration of 3G and maximum speed of 2.5m/s.
  • Multi-slider type mounting the synchronizing function promotes the efficiency of design for installation.
  • Abundant lineup consisting of compact shaft type of low cost, big sized type with high trust force etc.

IX Series

product_list1
SCARA robot

New robot of horizontal multi-jointed realized the top class performance in the industry and high cost performance.

  • Top level high speed, high carrying weight capacity and high accuracy in the class were realized.
  • Performance of trail accuracy and complementary function were improved significantly.
  • Press fitting or torque control of the work can be done with the Z axis pressing function.

TT Series

product_list1
Table top type robot

High performance robot of table top type realized the low price.

  • All in one type which is the most suitable for cell production or R&D. Lineup of 200mm x 200mm and 400mm x 400mm.
  • High rigid base, servo control motor are adopted. In addition, no step-out with the contained encoder.
  • High trail accuracy and X-SEL controller of constant speed is contained.
  • Lineup consisting of high rigid portal type, and cantilever type which emphasizes the working space.

Orthogonal type robot

product_list1

Intelligent actuator which has adaptable potential, and reduces the assembling manpower from design to introduction.

  • Various models are prepared from 5 kinds of bi-axis combination as a base, until 3 axis, 4 axis and 6 axis.
  • Wide covering area of 4,155mm x 400mm maximum. Cycle time can be reduced by the wide operating range and high speed performance of 2,500mm/s maximum.
  • IA kit which enables easy assembling of the Robo Cylinder as an orthogonal robot is of short delivery period and low price.

Controller

product_list1

Abundant controllers and peripheral equipment which can be applied to Robo Cylinder/single axis robot/orthogonal robot are fulfilled.

  • Operating pattern can be selected to meet the purpose.
    ＜Positioner type＞
    ＜Program type＞
    ＜Network type＞
  • To the various purposes for press fit operation and multiple positioning etc.
  • Connectible to field network such as DeviceNet, CC-Lin, ProfiBUS, EtherNet corresponding
  • Controller conforms with the European safety standard, and corresponding to CE marking.
